Max Driling (mm) : 16 mm (5/8″)
Motor Power : 750 w
Spindle Trave (mm) : 85 mm
Class Of Speed: 16
Speed 50Hz (mp):180 – 2770 rpm
Spindle Taper: MT2
Max. Distance From Spindle Axis To Surface Of Table (mm) : 150 mm
Max. Distance From Spindle End To Surface Of Table (mm) : 340 mm
Max. Distance From Spindle End To Surface Of Base (mm) : 540 mm
Swing (mm):325 mm
Table Size: 290 mm
Base Size: 230 x 400 mm
